Powerful NdFeB Material OEM Nickel Coating Sintered Permanent Strong Customized N52 Magnet
Product Details:
| Place of Origin: | China |
| Brand Name: | Monte Bianco |
| Certification: | ISO9001, ISO14001, TS16949 |
| Model Number: | N35-N52 (M.H.SH.UH.EH.AH) |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100PCS |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Standard Package |
| Delivery Time: | 15-30 working days after received your payment |
| Payment Terms: | T/T |
| Supply Ability: | 1000k pcs/month |
|
Detail Information |
|||
| Grade: | N52 | Coating: | Nickel, Zinc, Gold, Silver, Epoxy, Etc. |
|---|---|---|---|
| Size: | Customized | Tolerance: | ±1% |
| Magnetization: | Axial, Radial, Multi-poles | Material: | Sintered NdFeB |
| Working Temperature: | 80-220°C | Delivery Time: | 15-21 Days |
| Brand Name: | Monte-Bianco/OEM | Place Of Origin: | Hunan,China |
Product Description
Neodymium magnet also referred as NdFeB magnet because they are composed primaryly of Nedymium (Nd), Iron (Fe), and Boron (B).Neodymium magnet can be classified to sintered Neodymium magnet, Bonded Neodymium magnet, and hot-pressed Neodymium magnet according to the detailed manufacturing process. Sintered Neodymium magnet still offers the strongest magnetic power nowadays and has been widely served to vast kinds of application, include high-performance permanent motors, brushless DC motors, magnetic separators, magnetic resonance imaging (MRI), sensors, loudspeakers, consumer electronics, and green energy.
| Magnet Dimension | Custom dimension is available | |
| Magnetized Direction | Please indicate magnetization direction when ordering | |
| Magnet Grade | We can supply all grades of Ndfeb magnets | |
| For example:N35,N42,N52, N45sh,N42uh... | ||
| If you are not sure which grade is appropriate, please feel free to contact our engineers. | ||
| Temperature Resistance | Temperature is the first factor you must consider when choosing magnets, please contact our engineers for details. | |
| Coating | Customised (Zn, Ni-Cu-Ni, Ni, Gold, Silver, Copper, Epoxy, Chrome, etc) | |
| Max. Working Temperature | Grade | Max. Operating Temperatures |
| N35-N52 | 80°C (176°F) | |
| 33M- 48M | 100°C (212°F) | |
| 33H-48H | 120°C (248°F) | |
| 30SH-45SH | 150°C (302°F) | |
| 30UH-40UH | 180°C (356°F) | |
| 28EH-38EH | 200°C (392°F) | |
| 28AH-35AH | 220°C (428°F) | |
| Notice | 1. Be careful of fragile and clamped hands. | |
| 2. Store in a dry place at room temperature! | ||
| 3. Pull out carefully. When connecting the two magnets, slowly and gently close each other. Hard rolling can cause damage and cracking of magnets. | ||
| 4. Children are not allowed to play with naked Ndfeb magnets. | ||
1. Custom sizes -- (please specify all sizes in millimeters or inches).
*Arc magnet: outer diameter x inter diameter x width x thickness
*If you have special shape of the magnet,Please kindly provide sketches or drawing for us
2. Grade Choose -- (The higher the performance level, the stronger the magnetic force)
*N35, N38, N40, N42, N45, N48, N50, N52 (70-80°C)
*N35M, N38M, N40M, N42M, N45M, N48M, N50M (100-120°C)
*N30sSH, N33SH, N35SH, N35uh, N28eh, N30AH (150-230°C)
3. Surface coatings -- (Zinc and nickel-copper-nickel coatings are the most popular).
*There are many plating options such as nickel-copper-nickel, nickel, purple, gold, black epoxy etc
4. Quantity
*In order to provide an accurate competitive price, the number of magnets is essential.
Monte-Bianco Magnets Co., Ltd. is located in Changsha, Hunan Province. With more than 1000 skilled employees, our company has an annual production capacity of 2000 tons. Our company is able to supply a full range of products. It has been equipped with entire production capacity of product development, mold development and manufacturing, block production, finished product processing, surface treatment and other processes under fully controlled and managed process. Our products are widely used in power tools, new energy vehicles, energy-saving motors, wind power generation, high-end audio and other fields.
